SN

Items

Qty

Unit

Materials

1

Filling machine mainframe

Mainframe

1

Set

304 stainless steels

Cover plate

1

Set

304 stainless steels

Safety gate

1

Set

304 stainless steels

Airtight doors

2

Set

Aluminum alloy

Safety interlocks

1

Set

2

Cover-opening system

Cover-opening manipulator

1

Set

304 stainless steels

Translation system

1

Set

304 stainless steels

Lifting system

1

Set

304 stainless steels

Vision positioning system

1

Set

304 stainless steels

Covers in-feed system

1

Set

304 stainless steels

3

Filling module

High-precision lifting system (pneumatic)

2

Set

304 stainless steels for brackets

Vision positioning system

2

Set

304 stainless steels

4

Cover-closing system

Closing manipulator

1

Set

304 stainless steels

High precision linear translation system

1

Set

304 stainless steels

High-precision lifting

1

Set

304 stainless steels

Vision positioning system

1

Set

304 stainless steels for brackets

5

Intelligent volume control system

Filling lance

2

Set

304 stainless steels

Control device

2

Set

304 stainless steels

Control device (servo)

2

Set

304 stainless steels

Products hose

2

Set

6

Residual fluid

Collection device

2

Set

304 stainless steels

7

Weighing module

Weighing platform table

2

Set

Stainless steel 304 for Roller; carbon steel coated for bracket

Weighing platform bracket

2

Set

Carbon steel coated

Weighing sensor

2

Set

Aluminum alloy type sensor

8

Intelligent control system

Control cabinet

1

Set

304 stainless steels

Operation display

1

Set

Software control system

1

Set

Integration of original equipment control and the stabilizer adding equipment control

Cable trays

1

Set

Carbon steel coated

Electrical hardware

1

Set

9

Conveying System

Roller conveyor for empty drum;

8

M

304 stainless steels for roller, and coated carbon steel for rest of parts

Roller conveyor for filled drums

8

M

304 stainless steel for roller，and coated carbon steel for rest of parts

10

Operating unit

Operating table

1

Set

11

Re-inspection

Weighing platform table

1

Set

Weighing platform bracket

1

Set

Weighing sensor

1

Set

12

Rejection system

Shift Roller conveyor

1

Set

Roller conveyor

1

Set

13

Labelling

Side label

1

Set

Auto printer

1

Set

Top label

1

Set

Auto printer

1

Set

14

Automatic Palletizing

Transplanting palletizer

1

Set

Only for dispatching with pallets

Pallet supply warehouse

1

Set

Chain roller

5

M

15

Auto straping

Automatic horizontal strapping machine

1

Set

16

Auto wrapper

Auto rotary wrapper

1

Set
